Asrock RX6700 XT Challenger D 12GB OC, 12GB DDR6, PCIe4, HDMI, 3 DP, 2615MHz Clock, Ultra-fit Heatpipes, Overclocked
Specification
- Chipset Manufacturer: AMD
- Interface: PCI Express 4.0
- Graphics Chipset: AMD RX 6700 XT
- Memory Size: 12GB
- Memory Type: DDR6
- Memory Interface: 192-bit
- Core Clock:
- Boost Clock: Up to 2615 MHz
- Game Clock: Up to 2433 MHz
- Base Clock: 2330 MHz
- Memory Clock: 16 Gbps
- CUDA Cores / Stream Processors: 2560 Stream Processors
- Outputs:
- 1 x HDMI 2.1 VRR
- 3 x DisplayPort 1.4 with DSC
- HDCP Support: Yes
- Resolution: Digital Max Resolution: 7680 x 4320
- DirectX Support: DirectX 12 Ultimate
- Max Display Support: 4
- Cooling:
- Dual Fan Design
- Striped Axial Fan
- Ultra-fit Heatpipe
- 0dB Silent Cooling
- Super Alloy Graphics Card
- PSU Requirements: 650W or greater recommended
- Connectors Required: 2 x 8-pin PCIe power
- Additional Features: See Overview
- Dimensions: 269 x 134 x 41 mm
- Accessories: 1 x Quick Installation Guide
- Package Type: Retail
- Package Weight: 1.2000 kg
- Warranty: 2 Year Replacement Warranty
AMD Radeon RX 6700 XT Challenger D 12GB OC
- Boost Clock: Up to 2615 MHz / 16 Gbps
- Game Clock: Up to 2433 MHz / 16 Gbps
- Base Clock: 2330 MHz / 16 Gbps
- Graphics Chipset: 7nm AMD Radeon™ RX 6700 XT
- Memory Size: 12GB 192-bit GDDR6
- Architecture: AMD RDNA™ 2
- DirectX Support: DirectX 12 Ultimate
- Interface: PCI® Express 4.0 Support
- Power Connectors: 2 x 8-pin
- Outputs:
- 3 x DisplayPort™ 1.4 with DSC
- 1 x HDMI™ 2.1 VRR
- Cooling:
- Dual Fan Design
- Striped Axial Fan
- Ultra-fit Heatpipe
- Stylish Metal Backplate
- 0dB Silent Cooling
- Super Alloy Graphics Card
Cooling Features:
- Dual Fan Design: Provides strong cooling performance and a stylish design optimized for gaming.
- Stylish Metal Backplate: Prevents PCB bending and enhances cooling with premium thermal pads.
- Striped Axial Fan: Enhances airflow with a custom stripe structure and polished surface.
- 0dB Silent Cooling: Fan spins when needed and stops for complete silence.
- Ultra-fit Heatpipe: Maximizes contact for optimized heat dissipation.
- High-density Metal Welding: Improves heat dissipation by isolating gaps between pipes and fins.
- Nano Thermal Paste: Maximizes heat transfer and thermal efficiency.
- Premium Thermal Pad: Transfers heat to the heatsink for better heat dissipation.
- Precise Screw Torque: Optimizes cooler mounting pressure for improved thermal efficiency and GPU die protection.
- Dr. MOS: Integrated power stage solution delivering up to 60A continuous current for improved performance.
- Premium 60A Power Choke: Enhances Vcore voltage for improved stability.
- Nichicon 12K Black Caps: Provides longer lifespan and stability compared to standard capacitors.
- 2oz Copper PCB: Delivers lower temperature and higher energy efficiency.
- Matte Black PCB: A stylish matte black and copper color scheme.
- High Density Glass Fabric PCB: Reduces gaps between layers to protect against electrical shorts.
Additional Features:
- ASRock Tweak 2.0: Pro and easy-to-use tuning utility for smart fan control and performance tweaking.
- 8K Resolution Support: Supports 8K video output for an ultimate visual experience.
- PCI® Express 4.0 Support: Features enhanced bandwidth for next-gen gaming.
- AMD Eyefinity Technology: Expands screen area for a more immersive experience with multiple monitors.
- Powerhouse Performance for 1440p: Delivers high-performance gaming with 40 compute units, AMD Infinity Cache, and 12GB GDDR6 memory.
Vivid Visuals:
- AMD RDNA™ 2 Architecture: Enhances visual effects and gameplay across platforms.
- Elevated Experiences: Low-latency gaming technology, HDMI™ 2.1 VRR support, and compatibility with PCIe® 4.0 motherboards.
